Humminbird Xplore

Name: Humminbird Xplore
SKU: 8131
Availability: InStock

Price range: $980.00 through $2,400.00

Screen Size

Transducer Option

Clear

SKU: N/A Category: Humminbird

Overview

The XPLORE Series is lightning-quick and laser-focused on anglers’ favorite features. Find your fishing spots faster with included LakeMaster and CoastMaster charts. Sync 10,000 fish spots with custom colors and icons to your phone through a new waypoint management system. Get the clearest picture of what’s below with compatibility for our best sonar, including MEGA Live 2 forward-facing sonar. Connects to Minn Kota products and control them on command – from enabling Advanced GPS navigation to deploying shallow water anchors – with One Boat Network compatibility. With our most advanced technologies and easy-to-use interface, there’s more to XPLORE.

FEATURES

Full-HD Display with Cross Touch® interface
XPLORE delivers eye-popping detail with a 1280H x 720V display. See the incredible detail of sonar and chart images that will ensure you never miss a thing. Control it all using the touchscreen or the keypad—it’s up to you.

MEGA Side Imaging+
See the world below like never before with a crystal-clear Side Imaging viewing out to 200 feet on either side of your boat. You’ll unlock more fish and structure with 20% more detail and 60% more range capability than MEGA Side Imaging sonar.

MEGA Down Imaging+
Get unprecedented underwater clarity with Down Imaging coverage down to 200 feet below your boat. You’ll unlock more fish and structure with 20% more detail and 60% more depth capability than MEGA Down Imaging sonar.

Dual Spectrum CHIRP Sonar
Before you cast, know what’s down there thanks to highly-detailed fish arches and a clear view of fish-holding structure and the bottom. Powered by our proprietary, Low-Q CHIRP transducer, Dual Spectrum offers two ways to search; Wide Mode for maximum coverage and Narrow Mode for focusing on the slightest detail.

Internal GPS and Humminbird Basemap
Our enhanced basemap provides you with a clear view of underwater terrain and surrounding points of interest so you can fish and navigate with total confidence. Identify buoys, day markers, hazards, marinas, contours, depth markers and much, much more. Includes charts of more than 10,000 lakes, plus coastal coverage for the continental U.S.

Premium Chart Compatible
Humminbird provides the most complete offering of premium chart options to anglers everywhere. Get a complete view of the world below with optional charts from Humminbird’s LakeMaster® and CoastMaster™ products, as well as your choice of compatible Navionics® charts.

Includes LakeMaster® and CoastMaster® VX Maps
Navigate over 13,000 lakes, waterways, and coastal waters in the United States and Canada safely and with confidence. Tools like 1-foot contours, depth and shallow water highlights help you traverse waters with certainty.

Built-in SmartStrike™
Included with all LakeMaster® and CoastMaster® charts, SmartStrike™ highlights the best fishing spots based on real-time conditions—right from your map card

AutoChart Live
Create real-time maps of your fishing spots, with access to patented Humminbird® LakeMaster® features. Map depth contours, bottom hardness and vegetation as you drive your boat. Comes standard with eight (8) hours of built-in recording time and is compatible with AutoChart Zero Line SD cards for virtually endless AutoChart Live mapping capacity.

One-Boat Network Compatible
Many Humminbird models seamlessly integrate and communicate with Minn Kota and Cannon products to unlock more features and capabilities for anglers everywhere. Make the most of your time on the water with the exclusive boat control and fish-catching features of the One-Boat Network.

Ethernet Networking
High-speed Ethernet allows you to build a powerful, professional-grade fishing system. Easily connect multiple fish finders, or upgrade to add-on technologies like Minn Kota i-Pilot Link and Humminbird CHIRP Radar.

Bluetooth
Take control right from the screen of your Humminbird with wireless communication to compatible Talon and Raptor shallow water anchors, as well as Cannon Optimum downriggers. Additional features include wireless software updates from the Humminbird One-Boat App.

NMEA 2000 Networking Built-in
Connect an accessory NMEA 2000 network to your control head for even more information; from boat performance to weather and water conditions, make sense of it all with NMEA 2000 networking.

Compatible with MEGA Live 2 Sonar
Watch fish move, react, and strike your lure with the next-gen clarity of MEGA Live 2 in Forward or Down Mode, now with real-time zoom (Sold Separately).

In-Dash Installation Note
If indash mounted, an external GPS antenna is required to ensure accurate positioning and navigation.

Warranty
3-Year Limited Warranty with Registration

SPECS

Model	XPLORE 10 CMSI+ Fish Finder
Product Code	412010-1
Series	XPLORE
UPC	0082324058677
As shown MSRP
Display Size – Diagonal	10.1 in
Length	12.1 in \| 30.73 cm
Height	7.25 in \| 18.41 cm
Width	3.3 in \| 8.38 cm
Weight	4 lb 12 oz \| 2.15456 kg
Display Pixel Matrix	1280H x 800V
Transducer Included	XM 14 HW CMSI T
Compatible With	Minn Kota US2 Sonar, Minn Kota Built-In MEGA DI, Minn Kota Talon/Raptor, Minn Kota i-Pilot Link, Minn Kota Built-In MEGA SI, MEGA Live, NMEA 2000, MEGA 360, Radar, One-Boat Network, MEGA Live 2
Features	Touch Screen, Networking, Down Imaging, Built In GPS, Bluetooth, Side Imaging, Dual Spectrum CHIRP, Built In Mapping, MEGA Imaging+, Wi-Fi, MEGA Imaging
Memory Card Slot	Dual Micro SD
Sonar-Standard	Dual Spectrum CHIRP, MEGA Side Imaging+, MEGA Down Imaging+
Sonar-Coverage	20°, 42°, 60°, (2) 86° & (2) 55° @ -10dB
Sonar-Optional	50/83/200 kHz, Airmar High, High Wide, Medium, Medium Wide, and Low
CHIRP – Frequencies Supported	Narrow Mode (180-240 kHz), Wide Mode (140-200 kHz), Full Mode (150-220 kHz)

Sonar-Frequencies Supported	50/83/200/455/800 kHz, HW DSC CHIRP, and MEGA
Depth-Sonar	3,500 ft (optional 50 kHz), 1,200 ft (standard transducer)
CHIRP – Imaging Frequencies Supported	455 kHz SI+ (405-505 kHz), 455 kHz (420-520 kHz), MEGA SI+ (1050-1175 kHz)
Depth-Down Imaging	200 ft (MEGA), 400 ft (455 kHz)
Range-Side Imaging (Side-To-Side)	800 ft (455 kHz), 400 ft (MEGA)
Interface	Touch Screen, Keypad Control
Power Draw	2.2 Amps
Power Input	10.8-20 VDC
Power Output Peak-to-Peak	8000 Watts
Power Output RMS	1000 Watts
Screen Snap Shot	Included
Sonar Recording	Included
Mount-Standard	Gimbal
Mount-Standard Size	12.098 in W x 7.702 in H x 3.891 in D
Mount-Optional	In-Dash Mounting Kit
Mount-Optional Size	12.098 in W x 7.702 in H x 3.891 in D
Transducer Mount Location	Transom
GPS Chartplotting	Included
GPS Receiver	Internal
GPS Trackplotting	Not Supported
Waypoints, Routes, Tracks/Points	10,000, 50, 50/

360 Imaging Compatibility	Yes
MEGA Live Compatibility	Yes
Humminbird Basemap	Included
LakeMaster Compatibility	Yes
CoastMaster Compatibility	Yes
Navionics Gold/HotMaps Compatibility	Yes
Navionics Platinum+ Compatibility	Yes
Platinum Compatibility	Yes
Minn Kota Advanced GPS Navigation Compatibility	Yes
Minn Kota i-Pilot Link Compatibility	Yes
Minn Kota Talon Shallow Water Anchor Compatibility	Yes
Radar Compatibility	Yes
5-Port Ethernet Switch Compatibility	Yes
AIS Compatibility	Optional
Autopilot Compatibility	No
Heading Sensor GPS Compatibility	No
Heading Sensor GPS (NMEA 2000) Compatibility	Yes
NMEA2000	Included
Target Separation	2.5 in
Upgradable Software	Yes
View Preset Keys	Yes
X-Press Menu System	Yes
Custom Digital Readout	Yes
Custom View Selections	Yes
Display Colors Grayscale	24-Bit
Display Type	Color TFT
Speed	Included
Temperature	Built In
Temperature Alarm	Yes
Temperature Graph	Yes
HDMI Compatible	No
Warranty	Three-Year Warranty with Registration
